产品规格
| Max. Rotation Dia | Φ600mm |
| Max. Turning Dia | Φ550mm |
| Max. Dia Machining On The Tool Holder | Φ550mm |
| Max. Turning Length | 2000/3000mm |
| Bar Capacity | Φ105mm |
| Bar Capacity | Φ105mm |
| Spindle Head Type | A2–11 |
| Max. Spindle Speed | 860rpm |
| Worktable Dimensions | 350*2000/3000mm |
| X/Z Rapid Speed | X–Axis: 10m/min | Z–Axis: 10m/min |
| Positioning Accuracy | +-0.008/300mm |
| Repeatability | +-0.005/300mm |
| Turret Type | 4T Electric Tool holder |
| External Diameter Tool Holder | 40*40mm |
| Dia. Of Tailstock Sleeve | Φ100mm |
| Travel Of Tailstock Sleeve | 250mm |
| Taper Hole Of Tailstock Sleeve | Morse 5# |
| Machine Tool Dimensions | 6100*2100*2200mm |
| Machine Tool Weight | 9000Kg |
| Torque | Customizable configuration |
| Drilling Capacity | Customizable configuration |
| Voltage | 380V |
| Frequency | 50/60 Hz |
| Phase Type | 3–Phase Electricity |
| Color | Black |
| Usage/Application | Graphite Processing|Carbon Fiber Processing|Ceramic Processing|Composite Material Processing |
| Can it be customized | Supports customization |
| Guarantee | One year warranty for the whole machine |
| Brand | ShangshanJingji |
